Sony BKPF-L703A

Analogue Video Distribution Amplifier

The BKPF-L703 analog video distribution board accepts an NTSC/PAL composite analog video signal and distributes it to eight outputs.

The output cable length can be up to 300 m (Belden 8281, Fujikura 5C2V or equivalent cable).

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

• Passive loop-through output.
• Equalization for up to 300 m cable (Belden 8281, Fujikura 5C2V or equivalent cable).
• Clamping ON/OFF selectable.
• Differential input.




INPUTS Composite Video: BNC (x1 Input, x8 Outputs)
WEIGHT 0.56 lbs (0.26 kg)
OUTPUTS Composite Video: BNC (x1 Input, x8 Outputs)
DIMENSIONS Main Board: 10.75 x 3.125" (26.7 x 7.7cm)
POWER REQUIREMENT 5 VDC (Supplied from the PFV-L Series InterfaceUnit)




Standard Manufacturer's Warranty
