audio-technica U851A
CARDIOID CONDENSER BOUNDARY MICROPHONE
Ideal for sound reinforcement, professional recording and conferencing
PivotPoint® rotating output connector
Superior off-axis rejection for maximum gain before feedback
Outstanding rejection of radio frequency interference (RFI)
Small-diameter UniPoint capsule near boundary
Operates on battery or phantom power
U851A
CARDIOID CONDENSER BOUNDARY MICROPHONE
Offering outstanding Audio-Technica sound for surface-mount applications, the U851A features a PivotPoint® rotating output connector, UniSteep® filter and UniGuard® RFI-shielding technology. This battery or phantom-powered condenser microphone accepts interchangeable condenser elements available for boundary microphones in cardioid, hypercardioid and omnidirectional polar patterns. Its heavy die-cast case and silicon foam bottom pads minimize coupling of surface vibration to the microphone. With superior off-axis rejection and maximum gain-before-feedback, this professional microphone sets audio-quality standards in challenging acoustic environments.
- Designed for surface-mount applications such as high-quality sound reinforcement, professional recording, television, conferencing and other demanding sound pickup situations
- PivotPoint® rotating output connector allows cable to exit from either the rear or the bottom of the microphone
- Superior off-axis rejection for maximum gain before feedback
- UniGuard® RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
- UniSteep® filter provides a steep low-frequency attenuation to improve sound pickup without affecting voice quality
- Small-diameter UniPoint capsule near boundary eliminates phase distortion and delivers clear, high-output performance
- Heavy die-cast case and non-slip silicon foam bottom pads minimize coupling of surface vibration to the microphone
- Low-profile design with low-reflectance black finish for minimum visibility
- Operates on battery or phantom power
Element | Polarized condenser |
Polar Pattern | Half-cardioid (cardioid in hemisphere above mounting surface) |
Frequency Response | 30 - 20,000 Hz |
Open Circuit Sensitivity | Phantom: -40 dB (10.0 mV) re 1V at 1 Pa Battery: -41 dB (8.9 mV) re 1V at 1 Pa |
Impedance | Phantom : 200 ohms - Battery: 270 ohms |
Maximum Input Sound Level | Phantom: 133 dB, 1 kHz at 1% T.H.D. - Battery: 123 dB, 1 kHz at 1% T.H.D. |
Low Frequency Roll Off | 80 Hz, 18 dB/octave |
Switches | Off, on-flat, on-roll-off |
Dynamic Range | Phantom: 111 dB,1 kHz at Max SPL - Battery: 101 dB, 1 kHz at Max SPL |
Signal-to-Noise Ratio | 72 dB, 1 kHz at 1 Pa |
Phantom Power Requirements | 11-52V DC, 2 mA typical |
Battery Type | 1.5V AA/UM3 |
Battery Current/Life | 0.4 mA / 1200 hours typical (alkaline) |
Weight | 8.6 oz (244 g) |
Dimensions | 4.25" (108.0 mm) long, 3.31" (84.0 mm) maximum width, 0.91" (23.0 mm) height |
Output Connector | 3-pin XLRM-type |
Cable | 25.0' (7.6 m) long (permanently attached to microphone), 0.13" (3.2 mm) diameter, 2-conductor, shielded cable with TA3F-type connector |
Accessories Included | AT8531 power module; battery; soft protective pouch |
