audio-technica U853AU
UNILINE® CONDENSER HANGING MICROPHONE, BLACK
Designed for suspension over choirs, instrumental groups and theater stages
UniLine polar pattern provides narrow 90° acceptance angle
UniGuard® RFI-shielding technology offers outstanding rejection of RF
UniSteep® filter provides a steep low-frequency attenuation
Accepts interchangeable elements
Operates on battery or phantom power
U853AU
UNILINE® CONDENSER HANGING MICROPHONE, BLACK
Equipped with Audio-Technica's UniLine® line-cardioid element with a tightly focused 90º acceptance angle, the U853AU features UniGuard® innovations that offer unsurpassed immunity from radio frequency interference. The battery or phantom powered microphone accepts interchangeable elements, available in cardioid, hypercardioid, omnidirectional and UniLine® line cardioid polar patterns. It also offers an 80Hz low-cut UniSteep® filter that reduces pickup of low-frequency ambient noise.
- Designed for suspension over choirs, instrumental groups and theater stages
- UniLine polar pattern provides narrow 90° acceptance angle
- Superior off-axis rejection for maximum gain before feedback
- UniGuard® RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
- UniSteep® filter provides a steep low-frequency attenuation to improve sound pickup without affecting voice quality
- Accepts interchangeable elements to permit angle of acceptance from 90° to 360° : UE-C cardioid (120°); UE-H hypercardioid (100°); UE-O omnidirectional (360°)
- Low-profile design with low-reflectance finish for minimum visibility
- Available in two colors: black (U853AU) and white (U853AWU)
- Operates on battery or phantom power
| Element | Fixed-charge back plate, permanently polarized condenser |
| Polar Pattern | Line Cardioid |
| Frequency Response | 30 - 20,000 Hz |
| Open Circuit Sensitivity | Phantom: -38 dB (12.5 mV) re 1V at 1 Pa - Battery: 39 dB (11.2 mV) re 1V at 1 Pa |
| Impedance | Phantom: 200 ohms - Battery: 270 ohms |
| Maximum Input Sound Level | Phantom: 130 dB, 1 kHz at 1% T.H.D. - Battery: 120 dB SPL, 1 kHz at 1% T.H.D. |
| Low Frequency Roll Off | 80 Hz, 18 dB/octave |
| Switches | Off, on-flat, on-roll-off |
| Dynamic Range | Phantom: 110 dB, 1 kHz at Max SPL - Battery: 100 dB, 1 kHz at Max SPL |
| Signal-to-Noise Ratio | 74 dB, 1 kHz at 1 Pa |
| Phantom Power Requirements | 11-52V DC, 2 mA typical |
| Battery Type | 1.5V AA/UM3 |
| Battery Current/Life | 0.4 mA / 1200 hours typical (alkaline) |
| Weight | 30 g |
| Dimensions | 6.14" (156.0 mm) long, 0.48" (12.2 mm) diameter |
| Output Connector | Integral 3-pin XLRM-type |
| Cable | 25.0' (7.6 m) long (permanently attached to microphone), 0.13" (3.2 mm) diameter, 2-conductor, shielded cable with TA3F-type connector |
| Accessories Included | AT8154 two-stage foam windscreen; AT8451 steel hanger; AT8531 power module; AT8438 5/8"-27 stand adapter; battery |
