Blackmagic Design Micro Converter HDMI to SDI
With the Blackmagic Design HDMI to SDI Micro Converter you can convert a single high-definition HDMI signal into two 3G-SDI signals for ensuring workflow compatibility in professional video environments. Input signals are detected automatically, so the converter knows the resolution and format to output.
Blackmagic Design CONVCMIC/HS/WPSU Specs
| I/O | 1 x HDMI type A input 2 x SD/HD/3G-SDI BNC output 1 x micro-USB |
| Format Support | 1080p24/25/29.97/30/50/59.94 1080i50/59.94/60 720p50/59.94/60 NTSC PAL |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M |
| Color Precision | 4:2:2 |
| Color Space | YUV and RGB |
| OS Support | Mac OS X 10.10, 10.11 or later Windows 8.1, 10 |
| Power | Power input: 5 VDC via USB Micro-B Power consumption: 2.0 W Operational voltage range: 4.4 to 5.25 VDC |
| Environmental | Operating temperature: 32 to 104°F / 0 to 40°C Storage temperature: -4 to 140°:F / -20 to 60°C Relative humidity: 0 to 90% non-condensing |
| Dimensions | 3 x 1.8 x 1" / 76 x 46 x 25 mm |
| Weight | 5.3 oz / 150 g |
Packaging Info
| Package Weight | 0.785 lb |
| Box Dimensions (LxWxH) | 5.75 x 4.1 x 2.75" |
