Technical Specifications

• Ideal for use on board trains

  The camera is compliant with EN50155 and EN45545 safety standards for use aboard trains.

• See every detail with Full HD quality

  The sensitive, high-resolution Exmor CMOS sensor captures crisp, detail-packed Full HD (1920 x 1080) video images.

• Wide angle lens

  A very wide horizontal viewing angle of 113 degrees makes the camera ideal for video monitoring inside the confines of a train carriage.

• Latest generation imaging power

  High quality imaging is assured by Sony’s unique IPELA ENGINE EX signal processing platform that combines powerful signal processing with intelligent video analytics technologies. XDNR (eXcellent Dynamic Noise Reduction) assures clear low-light images, while Visibility Enhancer (VE) dynamically optimises brightness and colour reproduction on a pixel-by-pixel basis. Extra intelligence is added by DEPA Advanced analytics with face detection that can trigger alarms based on user-determined rules.

• Wide dynamic range

  Innovative View-DR technology achieves a dynamic range equivalent to 90 dB, capturing objects clearly and adaptively – even with harsh backlighting or sun-drenched highlights.

• Excellent low-light sensitivity

  The camera is capable of capturing clear images in very low light conditions: minimum illumination of 0.3 lx in Colour mode and 0.3 lx in B/W mode (at 50 IRE).

• Better pictures, day or night

  Electronic Day/Night function automatically switches the camera between Day (colour) and Night (B/W) modes, depending on light levels.

• Steadier, more stable images

  The in-built image stabiliser reduces the effects of camera shake or mechanical vibration for steadier images with reduced blur.

• Optimum picture quality in any situation

  A choice of selectable picture modes optimises camera settings for best picture quality in a wide range of applications and lighting environments.

• Recording quality to suit your network

  Select CBR (constant bitrate), VBR (variable bitrate) or VBR-with-cap compression modes for optimised recording quality depending on IP network conditions.

• Automatic edge recording to memory card

  Edge Storage allows recording of video and audio directly to an optional SD/SDHC card for later analysis.

• Built-in microphone

  Capture crisp, clear audio to hear what’s happening in the camera’s vicinity.

• Power over Ethernet with rugged M12 connector

  The camera is powered using PoE (IEEE 802.3af) via an industrial grade M12 connector, simplifying integration in a train carriage and eliminating the need for additional power cables.

• Flexible installation with three-axis lens adjustment

  This allows the lens unit to be turned in pan, tilt and rotate axes for easy and versatile camera angle adjustment.

• Built to handle tough conditions

  Ideal for use in indoor or outdoor areas, the camera can operate over a wide range of temperatures from -25°C to +50°C. It is vandal resistant with an IK10 impact rating and is IP66 rated against ingress by water and dust. A tamper alarm provides further protection against unwanted interference.

• View with your smartphone

  Securely access the camera using a smartphone or tablet (Android or iOS) to view images remotely.

• Easy IP network configuration

  Configuration of network settings is made quick and simple using the supplied SNC Easy IP Setup application.

• ONVIF (Open Network Video Interface Forum) compliance

  Support for ONVIF Profile-S simplifies integration with a wide range of VMS platforms and hardware, providing video streaming and camera control. ONVIF (Open Network Video Interface Forum) defines a common protocol for the exchange of information between network video devices, including automatic device discovery and video streaming.
